OPEN-GL Program

openGL logo

NAMA : RAFEL ILHAM ( 39110700 )
                FAHMI FADILLAH ( 39110981 )
KELAS: 2DB22

Membuat Lingkaran dengan OpenGL
#include <gl/glut.h>
#include <windows.h>
#include <math.h>

const double PI = 3.141592653589793;
int i,radius,jumlah_titik,x_tengah,y_tengah;
void Draw() {
        glClear(GL_COLOR_BUFFER_BIT);
        glColor3f(1.0, 1.0, 1.0);

        glBegin(GL_LINE_LOOP);
        radius=40;
        jumlah_titik=20;
        x_tengah=50;
        y_tengah=50;
        for (i=0;i<=360;i++){
        float sudut=i*(2*PI/jumlah_titik);
        float x=x_tengah+radius*cos(sudut);
        float y=y_tengah+radius*sin(sudut);
               glVertex2f(x/100,y/100);

        }
        glEnd();

        glFlush();
}

void Initialize() {
        glClearColor(0.0, 0.0, 0.0, 0.0);
        glMatrixMode(GL_PROJECTION);
        glLoadIdentity();
        glOrtho(0.0, 1.0, 0.0, 1.0, -1.0, 1.0);
}

int main(int iArgc, char** cppArgv) {
        glutInit(&iArgc, cppArgv);
        glutInitDisplayMode(GLUT_SINGLE | GLUT_RGB);
        glutInitWindowSize(250, 250);
        glutInitWindowPosition(200, 200);
        glutCreateWindow("Lingkaran");
        Initialize();
        glutDisplayFunc(Draw);
        glutMainLoop();
        return 0;
}
Running :


Menampilkan Garis dan Segitiga dengan OpenGL

Program untuk membuat garis adalah:
glBegin(GL_LINES);
glVertex3f(0.2, 0.2, 0.0);
glVertex3f(0.8, 0.2, 0.0);
glVertex3f(0.2, 0.5, 0.0);
glVertex3f(0.8, 0.5, 0.0);
glVertex3f(0.2, 0.8, 0.0);
glVertex3f(0.8, 0.8, 0.0);
glEnd();

Program Lengkap untuk membuat garis adalah:
#include <gl/glut.h>
void Draw() {
glClear(GL_COLOR_BUFFER_BIT);
glColor3f(1.0, 1.0, 1.0);
glBegin(GL_LINES);
glVertex3f(0.2, 0.2, 0.0);
glVertex3f(0.8, 0.2, 0.0);
glVertex3f(0.2, 0.5, 0.0);
glVertex3f(0.8, 0.5, 0.0);
glVertex3f(0.2, 0.8, 0.0);
glVertex3f(0.8, 0.8, 0.0);
glEnd();
glFlush();
}
void Initialize() {
glClearColor(0.0, 0.0, 0.0, 0.0);
glMatrixMode(GL_PROJECTION);
glLoadIdentity();
glOrtho(0.0, 1.0, 0.0, 1.0, -1.0, 1.0);
}
int main(int iArgc, char** cppArgv) {
glutInit(&iArgc, cppArgv);
glutInitDisplayMode(GLUT_SINGLE | GLUT_RGB);
glutInitWindowSize(250, 250);
glutInitWindowPosition(200, 200);
glutCreateWindow(“Line”);
Initialize();
glutDisplayFunc(Draw);
glutMainLoop();
return 0;
}

Running :


Menampilkan Segitiga

Perintah menampilkan segitiga adalah:

glBegin(GL_TRIANGLES);
glVertex3f(0.2, 0.2, 0.0);
glVertex3f(0.8, 0.2, 0.0);
glVertex3f(0.2, 0.5, 0.0);
glVertex3f(0.8, 0.5, 0.0);
glVertex3f(0.2, 0.8, 0.0);
glVertex3f(0.8, 0.8, 0.0);
glEnd();

Perintah lengkap menampilkan segitiga adalah :

#include <gl/glut.h>

void Draw() {
glClear(GL_COLOR_BUFFER_BIT);
glColor3f(1.0, 1.0, 1.0);
glBegin(GL_TRIANGLES);
glVertex3f(0.2, 0.2, 0.0);
glVertex3f(0.8, 0.2, 0.0);
glVertex3f(0.2, 0.5, 0.0);
glVertex3f(0.8, 0.5, 0.0);
glVertex3f(0.2, 0.8, 0.0);
glVertex3f(0.8, 0.8, 0.0);
glEnd();
glFlush();
}

void Initialize() {
glClearColor(0.0, 0.0, 0.0, 0.0);
glMatrixMode(GL_PROJECTION);
glLoadIdentity();
glOrtho(0.0, 1.0, 0.0, 1.0, -1.0, 1.0);
}

int main(int iArgc, char** cppArgv) {
glutInit(&iArgc, cppArgv);
glutInitDisplayMode(GLUT_SINGLE | GLUT_RGB);
glutInitWindowSize(250, 250);
glutInitWindowPosition(200, 200);
glutCreateWindow(“Triangles”);
Initialize();
glutDisplayFunc(Draw);
glutMainLoop();
return 0;
}

running :
